John Deere 4720 Forage Harvesters Technical Manual (TM1312)
Customer Reviews
Be the first to review this item. Share your rating and review so that other customers can decide if this is the right item for them.
Write a review
Name
E-mail
Review
Rating

John Deere 4720 Forage Harvesters Technical Manual (TM1312)

Number: 21315
Available
Add to Wishlist
Specifications
  • Type Of Document
    Technical Manual
  • Type of equipment
    Self-Propelled Forage Harvester
  • Model
    4720
  • Model
    4720
Details
Table of Contents:
   INTRODUCTION
   GENERAL
      Safety
      Specifications
      Lubrication
      Diagnosing Malfunctions
   DRIVE TRAIN
      Tractor Driveline
      Reverse Drive Gear Case
      Torque
      Rear Universal Drive
      Bevel Gear Case
      Feed Roll Drive Gear Case
      Troubleshooting
   HYDRAULICS
      General Information, Diagnosis and Tests
      Electrohydraulic Valves
      Torque Positioning Cylinder
      Feed Roll Shift Cylinders
      Cutterhead Lift Cylinders
      Spout Cap Cylinders
      Spout Control Motor
   ELECTRICAL
      Wiring Harness
      Diagnosis and Tests
      Electrical Adjustments
      Metal Detector
   CUTTERHEAD ASSEMBLY
      Feed Rolls
      Stationary Knife
      Cutterhead
      Knife Sharpener
      Troubleshooting
   MISCELLANEOUS
      Auger
      Fan
      Spout Liner
      Wheel Bearings
